ETA HR04 24V Submersible Solar Pump System

The ETA HR04 24V Submersible Solar Pump System is a durable, efficient positive-displacement submersible system built for deep wells and off-grid water applications. The HR series uses a helical rotor-and-stator pump coupled to a brushless continuous-duty motor, giving reliable performance in low-yield wells and abrasive conditions thanks to stainless steel internals. Capable of lifting water up to 400 ft and delivering approximately 1 GPM, the HR04 includes speed control to reduce output when required — very useful for conserving energy on small-yield wells. The pump can run Solar Direct (without batteries) for maximum daytime output, or be automated with a float switch or a pressure tank/switch for pressurized line applications. Built to be fully serviceable with rugged components and optional surface float capability for dugouts/reservoirs, the HR04 is a versatile choice for ranch, farm, and remote water systems. Warranty: 2 years.   FEATURES   Positive displacement helical rotor & stator pump Brushless continuous-duty motor with speed control Stainless steel interior resistant to abrasive wear 400 ft max vertical lift with ~1 GPM output Operates Solar Direct (no batteries) or with batteries Can be controlled by float switch or pressure tank/switch Adaptable for well or surface (dugout) applications Fully serviceable design for long-term maintenance 2-year manufacturer warranty   SYSTEM SPECIFICATIONS   Specification Details Pump Model ETA HR04 24V System Type Solar Submersible Pump (Positive Displacement) Flow Rate ~1 GPM Max Lift 400 ft (122 m) Operating Voltage 24 VDC Pump Type Helical Rotor & Stator (Positive Displacement) Control Speed control; PS2-200 controller included Duty Cycle Continuous Warranty 2 Years   INCLUDED SYSTEM COMPONENTS ETA HR04 pump wired with required length of wire and safety cable PS2-200 controller Solar modules Double solar module stand ETA charge controller Float switch (30 ft) Battery box Wiring package (plug & play ready)
